Inline Zinc Anode Shield
Protect Your Pool Equipment from Corrosion
FÉNIX Inline Zinc Sacrificial Anode Shield
FÉNIX Inline Zinc Sacrificial Anode Shield is designed to prevent galvanic corrosion in pool plumbing and equipment. By sacrificing itself, the zinc anode protects the metal components of your pool system from corrosion damage.
Effective protection for both saltwater and chlorinated pools. The zinc corrodes instead of your expensive equipment, extending their lifespan.
Technical Information:
| Model | Connection | A (mm) | B (mm) | C (mm) | Material |
|---|---|---|---|---|---|
| FDF63 | 63mm | Ø63 | 129 | 190 | ABS & PVC |
| FDF2.0 | 2.0" | Ø60 | 129 | 190 | ABS & PVC |
Product Dimensions:
Standard Installation:
Installation Steps:
- Cut pipe to match TEE shield size.
- Attach TEE using PVC glue.
- Secure copper wire to pump ground.
Recommended Location:
- For filter-only systems: after the filter.
- For systems with heater: after the filter and before the heater.
- For saltwater pools: after the filter and before the cell.
Replacement: The zinc anode should be replaced approximately every 3 years, or when it is more than 50% eroded.
